Cygnus DIVE Operating Manual
M2-DIVE-M-ENG_Iss5.docx
Page 38 of 118
When in Multip
le Echo mode and a
Multiple
Echo verification
has been found t
he three
echo points are
marked by three
square
boxes.
When in Single E
cho mode the echo po
int
is marked by a s
ingle arrow below the X
axis.
A-Scan Display in Single Echo Mode
In Single Echo mode th
e A-Scan display w
ill always be d
isplayed
and cannot be tu
rned off.
Surface Pr
eparation
The DIVE gauge will not m
easure through
barnacles or similar
hard encrusters.
You must therefo
re remove any h
ard marine
growth before att
empting a thickness
measurement, typ
ically
divers use a scraper to d
o this.
