Cygnus DIVE Operating Manual M2-DIVE-M-ENG_Iss5.docx

Page 49 of 118

directly underneath the probe face as the gauge may

incorrectly measure the depth of the couplant.

Large Corrosion Pits.

The A-Scan display can assist you - you will see a unclear

ultrasound signal with no distinct back-wall echo.

Corroded Metal

Couplant

Probe

Avoid Measuring Directly Over Corrosion Pits.

Pit
