15-1
15. REAR WHEEL/BRAKE/SUSPENSION/SWING ARM
SERVICE INFORMATION
● During servicing, keep oil or grease off the brake pads and brake disk.
● Inhaled asbestos fibers have been found to cause respiratory disease and cancer. Never use an air hose or dry brush to
clean brake assemblies. Use a brake cleaner, designed to minimize the hazard caused by airborne asbestos fibers.
SPECIFICATIONS
TORQUE VALUES :
EXHAUST MUFFLER LOCK BOLT 2.94~3.92㎏f·m
REAR AXLE NUT 7.84~9.8㎏f·m
REAR SHOCK ABSORBER LOWER MOUNT BOLT 1.96~2.94㎏f·m
REAR SHOCK ABSORBER UPPER MOUNT BOLT 3.92㎏f·m
REAR BRAKE CALIPER BOLT 1.96~2.94㎏f·m
15
SERVICE INFORMATION
······
15-1
TROUBLESHOOTING
··········
15-2
REAR BRAKE
··················
15-3
REAR FORK
····················
15-5
REAR WHEEL
··················
15-5
REAR CUSHION ADJUST
······
15-6
REAR CUSHION
················
15-6
ITEM STANDARD (mm) SERVICE LIMIT(mm)
REAR WHEEL RIM RUNOUT - 2.0
REAR SHOCK ABSORBER SPRING FREE LENGTH
232.9 235
REAR BRAKE DISK THICKNESS 3.5~3.8 3.0
REAR BRAKE DISK RUNOUT - 0.30
REAR BRAKE MASTER CYLINDER I.D. 14.000~14.040 14.050
REAR BRAKE MASTERCYLINDER PISTON O.D.
13.950~13.980 13.940
