2-9
INSPECTIONS / ADJUSTMENTS
BRAKE FLUID
● Remove the brake fluid cover.
● Check the oil level inside the front brake reservoir. If
the oil level is near the lower limit line, remove the
reservoir diaphragm and fill DOT 3 and DOT 4 brake
fluid to the top limit line.
● If the brake fluid reaches the lower limit line, check the
entire brake system for leaks.
BRAKE PAD/SHOE
BRAKE PAD REPLACEMENT
● Check the brake pads for wear.
● If the red mark on the pad reaches the brake disc,
replace the pads.
•Replace the brake pads in sets.
•Brake fluid will damage painted, plastic or rubber
parts.
•Mixing incompatible fluids can impair braking
efficiency.
•A leak in the brake system can lead to reduced
braking effiency and possible loss of braking ability.
BRAKE SYSTEM
● Check the front brake hose for cracks or damage. If any
leaks are found, replace immediately.
● Check the brake rod for looseness or damage, and
replace it if necessary.
BRAKE LEVER FREE PLAY
● Check the free play after pulling the lever.
FRONT : 10~20mm
REAR : 10~20mm
