DAELIM S2 250 Service Manual

2-1
2. INSPECTIONS/ADJUSTMENTS
SERVICE INFORMATION
•The exhaust gas contains poisonous substance. Do not keep engine idling in a closed or poorly ventilated place for a
long period of time.
•Refer to 2~3, 2~4 with respect to Engine oil and oil filter.
•Stand the main stand prior to beginning work.
SPECIFICATIONS
2
SERVICE INFORMATION
······
2-1
MAINTENANCE SCHEDULE
····
2-3
FUEL LINE
··················
2-4
THROTTLE GRIP OPERATION
····
2-4
AIR CLEANER
··············
2-5
SPARK PLUG
····················
2-5
VALVE CLEARANCE
············
2-5
CYLINDER COMPRESSION PRESSURE
··
2-6
CARBURETOR IDLING
········
2-6
FINAL REDUCTION GEAR OIL
····
2-6
GEAR OIL REPLACEMENT
······
2-7
DRIVE BELT
····················
2-7
COOLING LEVEL INSPECTION
··
2-8
COOLANT REPLACEMENT
····
2-8
BRAKE FLUID
··················
2-9
BRAKE PAD
····················
2-9
BRAKE SYSTEM
················
2-9
SIDE STAND
····················
2-9
SUSPENSION
··················
2-10
BOLTS, NUTS, FASTENERS
····
2-10
WHEELS / TIRES
················
2-11
STEERING HEAD BEARING
····
2-11
THROTTLE GRIP PLAY 2- 6mm
SPARK PLUG DPR7EA-9
SPARK PLUG GAP 0.9mm
IN 0.1mm
EX 0.1mm
CARBURETOR IDLE SPEED 1,700±100rpm
CYLINDER COMPRESSION PRESSURE 15±2kgf/
㎠㎠
DISASSEMBLY 1.1
REPLACE 0.9
DISASSEMBLY 0.2
REPLACE 0.18
RADIATOR CAPACITY 1,000 20cc
COOLANT CAPACITY 1,400
20cc
RESERVE TANK CAPACITY 400
20cc
VALVE CLEARANCE
ENGINE OIL
GEAR OIL
