3-7
EXTERNAL PARTS
● Loosen the 4 tapping screws securing the inner cover
INNER COVER
● Remove the front cover and windscreen
● Remove the coolant reserve tank
● Remove the fuel tube clip
● Remove the breather tube
● Loosen the 3 screws securing the inner cover
● Remove the bag holder
● Loosen the 2 tapping screws securing the speedometer
cover
● Install in the reverse order of removal
SPEEDOMETER COVER
● Remove the speedometer cable
● Remove the coupler and wire
● Loosen the 2 tapping screws secring the speedometer
cover
● Install in the reverse order of removal
