AUTO BYSTARTER

INSPECTION/REMOVAL

AUTO BYSTARTER INSPECTION

● Measure the resistance between the auto bystarter wire

terminals.

Resistance : 10Ω(minutes minimum after stopping

the engine)

AUTO BYSTARTER REMOVAL

● Remove the one set plate screw and set plate and then

remove the auto bystarter from the carburetor body.

● Check the auto bystarter valve and needle for nicks,

wear or damage.

● If any faulty part is found, replace the auto bystarter

with a new one.

● Connect the hose to the fuel enriching circuit of the

carburetor. Connect the auto bystarter green/back wire

to the positive (+) terminal of a battery and black/white

to the neagtive (-) terminal. Wait 5 minutes and blow

the hose with mouth. If the passage is blocked, the auto

bystarter is normal.

● Disconnect to auto bystarter from the battery. Wait 30

minutes and blow the hose with mouth. If air can be

blown into the hose, the auto bystarter is normal.

5-7

FUEL SYSTEM

•If the reading is not within the limit, replace the auto

bystarter with a new one.

AUTO BYSTARTER

SCREWS

SET PLATE

BYSTARTER VALVE

BYSTARTER NEEDLE
