6-7

COOLING SYSTEM

● Connect the overflow tube and secure with the tube

clamp.

● Fill the radiator with coolant.

● Connect the vent tube to the radiator filler.

● After installation, check for coolant leaks.

● Install the front cover.

WATER PUMP

MECHANICAL SEAL (WATER SEAL)

INSPECTION

● Inspect the telltale hole for signs of mechanical seal

coolant leakage.

● If the mechanical seal is leaking, remove the right

crankcase cover and replace the mechanical seal.

WATER PUMP/IMPELLER REMOVAL

● Remove the coolant inlet hose and outlet hose.

·If you want to refill the coolant, the following

procedure must be checked.

1. Please make the radiator filler and the air vent tube

to tbe separated.

2. Then start th engine, filled in the coolant till the

coolant flowed out from the air vent tube.

3. Put the air vent tube on.

TELLTALE HOLE

WATER PUMP

INLET HOSE

OUTLET HOSE
