95XF series Inspection and adjustment
EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES
3-47
3.41 CHECKING THE AIR SUSPENSION BELLOWS
1. Raise the chassis to its highest position
using t he remote control.
2. Clean the air bellows using a cleaning rag
or a soap solution, if required.
3. Check the air bellows for cracks and
damage. If cracks or damage are found
through which the webbing is visible, the air
bellows should be replaced.
4. Check the air bellows, bellows seating and
air line connections for leaks.
Check that the air bellows, when in their
highest position and in driving position, do
not rub against air lines etc.
M9040
3.42 CHECKING THE OPERATION OF THE AUTOMATIC LUBRICATION SYSTEM
1. Check the system f or line fracture and
operation of the jets.
2. Check whether all lubricating points are
lubricated.
3. Check the lubricant level in the reservoir. If
required, top up the reservoir, see chapter
“Draining and filling”.
W 9 07 004
1
5
200424
