95XF series Cleaning
EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES
6-5
1. Insert radiator cleaner (4) between
intercooler (1) and radiator (2), from the
bottom upwards, with the air holes facing
the intercooler (1).
2. Apply air pressure to the radiator cleaner (4)
and continue blow-cleaning the
intercooler (1) until no more dirt comes out.
1
2
3
4
M2109
P
3. Turn the radiator cleaner over, turning the
holes towards the radiator (2), and
blow-clean the radiator (2).
1
2
3
4
M2110
P
6.5 CLEANING THE FUEL COARSE FILTER
1. Remove the fuel coarse filter. See “Removal
and installation”.
2. Rinse the coarse filter with clean diesel fuel.
3. Blow-clean the coarse filter with
compressed air, maximum pressure approx.
1 bar.
5
200424
