DAF 95XF - Draining and Filling, Wheel Hub

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES
Draining and filling 95XF series
5-10
5.5 DRAINING AND FILLING, WHEEL HUB
To prevent skin injury, avoid
unnecessary contact with the
drained oil.
1347 axle
Draining the wheel hub
1. Position the vehicle on a level surface.
2. Position the wheels so that the level
check/filler plug (A) is at the underside.
3. Remove the level check/filler plug (A) and
drain the oil.
Filling the wheel hub
1. Position the vehicle on a level surface.
2. Position the wheels so that the arrow on the
hub cover is facing upwards vertically.
3. Fill the hub with the specified quantity of oil.
See ”Technical data”.
4. Check the oil level after approximately 5
minutes. See ”Inspection and adjustment”.
M8010
A
5. Fit the level check/filler plug (A) ) using the
special Torx wrench (DAF no.1329422) and
tighten the plug to the specified tightening
torque. See ”Technical data”.
M8009
A
5
 200424
