95XF series Draining and filling
EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES
5-11
1354 and 1355 (T) axle
Draining the wheel hub
1. Position the vehicle on a level surface.
2. Position the wheels in such a way that the
drain/filler plug (A) is on the underside.
3. Remove the drain/filler plug (A) and level
check plug (B) and drain the oil.
B
A
A8 00 363
Filling the wheel hub
1. Position the vehicle on a level surface.
2. Position the wheels in such a way that the
drain/filler plug (A) is on the top side.
3. Fill the hub with the specified quantity of oil.
See ”Technical data”.
4. Check the oil level after approximately 5
minutes. See ”Inspection and adjustment”.
5. Fit the level check plug (B) and the
drain/filler plug (A) using the special torx
wrench (DAF no. 1329422) and tighten the
plug to the specified tightening torque. See
”Technical data”.
A
A8 00 364
