DAF 95XF - Inspection and Adjustment, Wheel Bearing Play

95XF series Inspection and adjustment
EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES
3-51
3.46 INSPECTION AND ADJUSTMENT, WHEEL BEARING PLAY
FRONT AXLE/TRAILING AXLE 09N075/LEADING REAR AXLE
Checking the wheel bearing play
1. To make sure that the inspection of the
wheel bearing play is r eliable, use the
special tool (DAF no. 0535595).
The s pecial tool consists of:
1. extensions
2. central nut
3. dial gauge holder
4. threaded spindle
5. bridge
6. socket wrench
7. additional extension pieces
2. Remove the hub cap.
3. Remove two opposite wheel nuts.
S7 00 131
1
7
6
4
5
3
2
4. Fit the extensions (1) onto the vacant wheel
studs. The extensions belonging to the set
should now be extended using the
additional extension pieces (7).
S7 00 079
5. Place the dial gauge holder (3) on the
central nut (2).
S7 00 080
5
