DAF 95XF - Removal and Installation, Gearbox Oil Filter

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES
Removal and installation 95XF series
4-22
4.15 REMOVAL AND INSTALLATION, GEARBOX OIL FILTER
To prevent skin injury, avoid
unnecessary contact with the
drained oil.
Gearbox 16S-181/221 with integrated retarder
Removing the gearbox oil filter
1. Remove the attachment bolt (1) of the oil
filter.
M3052
1
2. Pull the filter cover with the filter from the
filter housing.
M3053
3. Remove the filter (3) from the filter cover
(2). Do not clean the filter. The filter must
always be replaced.
Note:
If the magnetic disc is still attached to the
back of the filter, separate it from the filter
element and fit it to the new filter element.
M3054
2
3
5
 200424
