95XF series Removal and installation
EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES
4-23
Installing the gearbox oil filter
1. Check the O-ring of the filter cover (2) for
any damage. Replace the O-ring if
necessary. Grease the O-ring.
2. Grease the O-ring of the new filter (3) and
place t he filter on the filter cover.
Then insert the filter and the filter cover into
the f ilter housing.
3. Use a plastic mallet to tap the filter cover
into the filter housing.
4. Tighten the attachment bolt (1) to the
specified t ightening torque, see “Technical
data”.
M3052
1
5
200424
