95XF series Rear axle
TECHNICAL DATA
4-1
4. REAR AXLE
4.1 GENERAL
Wheel bearing play, 1347 axle 0.025 - 0.25 mm
4.2 TIGHTENING TORQUES
Filler and drain plugs/hub plugs (Torx wrench) 85 Nm
M24 hexagon U-bolt nut, property class 8 600 Nm*
M24 hexagon U-bolt nut, property class 10 770 Nm*
M22 hexagon U-bolt nut (tandem axle),
property class 10
555 Nm*
* Evenly tighten the two U-bolt nuts
alternately.
4.3 FILLING CAPACITIES
Differential
1347 axle
Minimum caster Maximum caster
Filling capacity approx. 21.5 litres approx. 23.5 litres
1354 axle
Filling capacity approx. 16.5 litres
1355T axle
Minimum caster Maximum caster
1st axle capacity approx. 13.0 litres approx. 18.0 litres
2nd axle capacity approx. 11.5 litres approx. 13.0 litres
Wheel hub
1347 axle
Filling capacity per hub approx. 0.9 litres
1354 axle
Filling capacity per hub approx. 2 litres
1355T axle
Filling capacity per hub approx. 2 litres
