95XF series Removal and installation
EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES
4-5
4.4 REMOVAL AND INSTALLATION, AIR FILTER ELEMENT
Removing the air filter element
1. Loosen the retaining clamps (1) on the air
filter cover (2).
2. Remove the air filter cover.
3. Remove the air filter element (3).
4. Check the air f ilter element for damage. If
the air filter element or its seals are
damaged, the air filter element must be
replaced.
5. Clean the inside of the air filter housing and
the air filter cover.
6. If required, clean the air filter, see chapter
“Cleaning”.
7. When replacing the air filter element, reset
the air filter indicator, if fitted, by pressing
the button on the upper side of the indicator.
Installing the air filter element
1. Fit the air filter element in the air filter
housing.
2. Fit the air filter cover, making sure the arrow
on the cover points upwards.
Note:
This position is important if a rubber sealing
valve has been installed on the air filter
cover.
3. Fit the retaining clamps.
4. Check that the flexible bellows-type sealing
cover (5) on the air intake is not damaged.
Replace if necessary.
Important!
The filter element can be cleaned once, after
which it must be renewed.
i 400207
32
1
M200729
5
M2116
5
200424
