DAF 95XF - Removal and Installation, Deb

95XF series Removal and installation
EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES
4-19
4.12 REMOVAL AND INSTALLATION, DEB
Make sure that the spring plate (5)
under the main piston (4) is not
damaged or deformed.
If this spring plate is damaged or
deformed it could break off while
the DEB is engaged, resulting in
serious engine damage.
When the engine or parts thereof
are opened, it is possible for dirt to
penetrate w hich can result in
serious damage to the engine. So
clean the engine thoroughly before
opening any parts of it.
Removing the DEB
1. Remove the valve covers.
2. Disconnect the electrical connection and
remove t he cable harness from its housing.
3. Remove the DEB attachment bolts and the
DEB assembly.
Installing the DEB
1. Tighten the rocker s eat attachment bolts to
the s pecified torque. See “Technical data”.
Note:
There are two different DEB housings for
cylinders 1 to 3, and cylinders 4 to 6. This is
indicated on the DEB housing.
2. Place the DEB on the rocker seats.
3. Insert the DEB attachment bolts and tighten
them to the specified torque. See “Technical
data”.
4. Connect the electrical connections.
5. Adjust the v alve clearance.
6. Adjust the DEB clearance. See “Inspection
and adjustment”.
7. Fit the v alve covers.
1
2
4
5
3
6
i 400167
i 400187
5
 200424
