EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES
Removal and installation 95XF series
4-18
VF engine
Removing the valve cover
1. Clean the area around the valve cover.
2. Remove the attachment bolts from the valve
cover.
3. Remove the valve cover and the gasket.
Installing the valve cover
1. Clean the sealing face of the valve cover.
2. Fit the v alve cover using the valve cover
gasket.
The v alve cover gasket, if not damaged,
may be reused (do not use solvents for
cleaning the gasket).
The marking “TOP” on the gasket should
point in the direction of the valve cover.
3. Fit the attachment bolts of the valve cover
and tighten them to the specified torque.
See “Technical data”.
5
200424
