DAF 95XF - Removal and Installation, Wheel Hub

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES
Removal and installation 95XF series
4-24
4.16 REMOVAL AND INSTALLATION, WHEEL HUB
FRONT AXLE/LEADING REAR AXLE/TRAILING AXLE 09N075
3
4
5
6
7
8
10
11
12
13
14
9
S7 00 401
2
1
Removing the wheel hub
1. Jack up the axle until the wheels are clear
from the floor and position suitable stands
under the axle.
2. Release the brake shoes.
3. Remove the hub cap (2).
4. Tap back the locking washer (4) and
remove the lock nut (3) from the axle journal
using t he socket spanner (A), special tool
(DAF no. 0535832).
5. Remove the locking washer (4) and the
circlip (5) from the axle journal.
6. Position a tyre lift under the wheel.
A
S7 00 084
5
