DAF 95XF - Page 145

95XF series Removal and installation
EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES
4-25
7. Remove the adjusting nut (6) from the axle
journal using adjusting spanner (A), special
tool (DAF no. 0694783).
8. Remove the outer wheel bearing (7) from
the hub (8).
Note:
If the bearings are removed from both
wheels, the bearings should be marked.
Each bearing should be reinstalled in its
original hub.
9. Remove the hub with the wheel from the
axle journal.
Avoid damaging the wheel speed sensor
ring (10.
10. Remove the hub seal (14).
11. Remove the inner wheel bearing (13) from
the hub.
12. Remove the grease f rom the hub (9) and
clean the hub.
13. Thoroughly clean the bearing c ages using a
cleaning liquid.
14. Remove the outer races ( 8) and (12) of the
wheel bearings, if necessary.
S7 00 404
A
6
5
 200424
