95XF series VF engine
TECHNICAL DATA
2-1
2. VF ENGINE
2.1 GENERAL
Valve clearance
(cold)
Inlet valve 0.35 mm
Exhaust valve 0.70 mm
Unit injector
Setting value for unit injector (cold) 0.50 - 0.75 mm
C-brake
Setting value for C-brake (cold) 0.58 mm
V-belt tension
Belt tension for poly V-belts in Newtons (N)
6-rib version 10-rib version
New poly V-belt 700 1100
Run-in poly V-belt
1
300 - 600 450 - 900
(1)
A run-in poly V-belt is a belt which has been used for
10 minutes or longer.
If the belt tension of a run-in poly V-belt is below the
minimum permitted tension, it should be adjusted to
the maximum permitted tension.
200424
