95XF series Leading rear axle 09N044 (FTP-type vehicles)
TECHNICAL DATA
10-1
10.LEADING REAR AXLE 09N044 (FTP-TYPE VEHICLES)
10.1 GENERAL
Wheel bearing play 0 mm
10.2 TIGHTENING TORQUES
The tightening torques stated in this paragraph
are different from the standard tightening
torques stated in the overview of standard
tightening torques. Any other threaded
connections that are not specified must
therefore be tightened to the tightening torque
stated in the overview of standard tightening
torques.
When attachment bolts and nuts are to be
replaced, it is important that they are of exactly
the same length and property class as the ones
removed, unless stated otherwise.
Hub nut 100 Nm
(1)
Hub cap 500 Nm
U-bolt nut M20, property class 10 553 Nm
(2)
(1)
Turn back until split pin can be fitted.
(2)
Evenly tighten the two U-bolt nuts alternately.
