EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES
Inspection and adjustment 95XF series
3-6
4. Check and correct the valve clearance of
cylinder 6. The correct valve clearance is
adjusted by loosening the lock nut and
turning t he adjusting bolt in the correct
direction. See “Technical data” for the
correct valve c learance.
M200540
5. By always cranking t he camshaft by 1/3 of a
stroke using the special tool
(DAF no. 1310477), t he valves can be
adjusted according to the injection
sequence 1-5-3-6-2-4.
Valve overlap of
cylinder
Set valves
of cylinder
1 6
5 2
3 4
6 1
2 5
4 3
6. If the engine has been fitted with a DEB, the
DEB clearance must be checked following
the v alve clearance adjustment.
7. Fit the v alve covers. See “Removal and
installation”.
5
200424
