Local Basic Operation 148
Click the Enter Menu icon to open
the MENU OPERATION interface.
4.4.3 Configuring PTZ Functions
4.4.3.1 Configuring Presets
Step 1 On the Expanded PTZ Control Panel, click .
The Preset interface is displayed. See Figure 4-86.
Figure 4-86
Step 4 Click the direction arrows to the required position.
Step 5 In the Preset box, enter the value to represent the required position.
Step 6 Click Setting to complete the preset settings.
4.4.3.2 Configuring Tours
Step 1 On the Expanded PTZ Control Panel, click .
The PTZ interface is displayed.
Step 2 Click the Tour tab.
The Tour tab is displayed. See Figure 4-87.
Figure 4-87
Step 3 In the Patrol No. box, enter the value for the tour route.
Step 4 In the Preset box, enter the preset value.
Step 5 Click Add Preset.
