Local Basic Operation 150
Figure 4-89
Step 3 Click the direction arrows to position the left and right borders.
4.4.4 Calling PTZ Functions
After you have configured the PTZ settings, you can call the PTZ functions for monitoring from
the Expanded PTZ Control Panel. See Figure 4-90.
Figure 4-90
4.4.4.1 Calling Presets
Step 1 On the Expanded PTZ Control Panel, in the No. box, enter the value of the preset that
you want to call.
Step 2 Click to call the preset.
Step 3 Click again to stop calling the preset.
4.4.4.2 Calling Tours
Step 1 On the Expanded PTZ Control Panel, in the No. box, enter the value of the tour that you
want to call.
Step 2 Click to call the tour.
Step 3 Click again to stop calling the tour.
4.4.4.3 Calling Patterns
Step 1 On the Expanded PTZ Control Panel, in the No. box, enter the value of the pattern that
you want to call.
Step 2 Call to call the pattern.
