Local Basic Operation 275
If the web interface of the Device is displayed, the configuration is successful. If not, the
configuration is failed.
4.12.5 UPnP
You can map the relationship between the LAN and the WAN to access the Device on the LAN
through the IP address on the WAN.
Preparations
Login the router to set the WAN port to enable the IP address to connect into the WAN.
Enable the UPnP function at the router.
Connect the Device with the LAN port on the router to connect into the LAN.
Select Main Menu > NETWORK > TCP/IP, configure the IP address into the router IP address
range, or enable the DHCP function to obtain an IP address automatically.
Configuration Steps
Step 1 Select Main Menu > NETWORK > UPnP.
The UPnP interface is displayed. See Figure 4-206.
Figure 4-206
