Dahua DHI-NVR5208-4KS2 - NVR21 HS-W-4 KS2 Series

Front Panel and Rear Panel 15
Figure 2-13
Table 2-11
Icon
Name
Function
HDD
HDD status indicator
light
The blue light is on when the HDD is malfunction.
NET
Network status indicator
light
The blue light is on when the network connection is
abnormal.
PWR
Power status indicator light
The blue light is on when the power connection is
OK.
2.1.12 NVR21HS-W-4KS2 Series
The front panel is shown as below. See Figure 2-14.
Figure 2-14
