Local Basic Operation 194
Table 4-32
Select a preset you want to use IVS
Input customized rule name
System can generate an alarm once the object is in the zone for the specified
period.
Click to filter the target. Check the blue wireframe and adjust the size of
the area with the mouse.
Each rule can set 2 target filters (maximum size and minimum size), that is,
when the passing target is smaller than the minimum target or larger than the
maximum target, no alarm will be generated. The maximum size should not
be smaller than the minimum size.
3) Draw a rule. Left click mouse to draw a zone, until you draw a rectangle, you can
right click mouse.
4) Click OK to complete the rule setting.
Step 3 Click , you can refer to the "4.7.2.4.1 Tripwire" to set other parameters.
Step 4 Click Apply to complete the setup.
4.7.2.4.4 Fast moving
You can detect the fast moving object in the specified zone.
Step 1 In the Type drop-down list, select Fast Moving.
The interface is shown as below. See Figure 4-136.
