ESS Series User’s Manual
83
5.3 ESS3116S-J/ESS3116S-JR
5.3.1 Front Panel
The front panel is shown as below. See Figure 5-4.
Figure 5-4
Please refer to the following sheet for detailed information.
SN
Name
Function
1
Power on-off button
Press it to boot up the device.
Press it for 5 seconds to shut down the device.
2
HDD Indicator Light
When system HDD is reading or writing, the blue light becomes flash.
3
Alarm Indicator Light
The red light is flashing when there is an alarm or abnormal situation.
4
Network Indicator
Light
The blue light is flashing when the network connection is OK.
5
Front Panel Locker
Secure it to lock the panel. It has the dustproof function. It can reduce
the risk of the HDD stealing or mistakenly remove operation.
5.3.2 Rear Panel
The rear panel has two types: single power and redundancy power. These two types have slight
difference on the power module and fan module. Please check carefully.
The single power mode rear panel is shown as below. See Figure 5-5.
Figure 5-5
The redundancy power series rear panel is shown as in Figure 5-6.
