QuIcK Menu
Items in the Quick Menu (see Table 2) contain basic unit operating status and control set point parameters. The items shown in the
Quick Menu are Read Only if a valid password has not been entered. The following are brief descriptions of the Quick Menu items.
No password is required to view the Quick Menu.
Table 2: Quick Menu
Menu Display Name Default Setting Range Password Level
Unit State= —
Off
None
Start
Recirc
Fan Only
Min DAT
Htg
Econo
Clg
Unit Status= —
Enable
6
Off Man
Off Mn Ctl
Off Net
Off Alm
Off Fn Rty
Dehum Status= — Active/Inactive 6
Ctrl Mode= Off
Off
6
Heat Only
Cool Only
Fan Only
Heat Cool
Auto/Net
Occ Mode= Auto/Net
Occ
6
Unocc
Tnt Ovrd
Auto/Net
HP Mode= Auto Cool Only/Auto 6
Clg Capacity= — 0–100% None
OAD/Econo Cap= — 0–100% None
Htg Capacity= — 0–100% None
Supl Htg Capacity — 0–100% None
Reheat Capacity= — 0–100% None
Control Temp= — -50.0–200.0°F None
Occ Clg Spt= 72.0°F 0.0–100.0°F None
Occ Htg Spt= 68.0°F 0.0–100.0°F None
Disch Air= — -50.0–250.0°F None
DAT Clg Spt= 55.0°F 40.0–100.0°F None
DAT Htg Spt= 85.0°F 40.0–140.0°F None
Unocc Clg Spt= 85.0°F 40.0–100.0°F None
Unocc Htg Spt= 55.0°F 40.0–100.0°F None
Min DAT Limit= 55.0°F 0.0–70.0°F None
SAF Speed= — 0–100% None
Duct Press= — 0.2–4.0 in None
Duct SP Spt= 1.0 in 0.2–4.0 in None
RF/EF Cap= — 0–100% None
Bldg Press= — -0.25–0.25 in None
Bldg SP Spt= 0.050 in -0.25–0.25 in None
IAQ PPM= — 0-5000ppm 4
OA Flow= — 0–60000 CFM 4
MinOAFlw Spt= 2000 CFM 0–60000 CFM 4
OA Temp= — -50.0–200.0°F None
Rel Humidity= — 0–100% None
