Heating Set-Up
(See page 83 and 108 for more information)
The Heating Set-Up menu provides a summary of the control
parameters for non-heat pump units with heating or heat pump
units with supplemental heating. The unit’s heating mode of
operation is controlled by the control temperature and the
heating set point temperature. The unit goes into the heating
mode of operation by analyzing the control temperature.
The control temperature can be return temperature, space
temperature or outside air temperature. The unit goes into the
heating mode of operation when the control temperature is
below the heating set point by more than ½ the deadband.
Table 29: Heating Set-Up Menu
Item Display Name
Default
Setting
Range
Password
Level
Htg Stage Time= 5min 2–60min 4
Htg DB= 2.0°F 1.0–10.0°F 4
Htg Period= 60s 0–999s 4
Htg Gain= 0.1 0.0–100.0 4
Htg PAT= 600s 0–999s 4
Htg Max Chg= 10% 0–100% 4
Htg Lo OAT Lock= 0°F -50–50°F 4
Htg Hi OAT Lk= 55°F 0–100°F 4
Eff Htg Hi OAT Lk= — 0–100°F 4
SuplHtg Hi OAT
Lock=
55°F 0–100°F 4
OAT Diff= 2°F 0–10°F 4
Htg Reset= None
None
6
Ntwrk
Space
Return
OAT
ExtmA
ExtV
Min Htg Spt= 55.0°F 40.0–140.0°F 6
Min Htg Spt @=
0/ 0–100/
6
NA
NA
°F
°C
mA
Max Htg Spt= 55.0°F 40.0–140.0°F 6
Max Htg Spt @=
0/ 0–100/
6
NA
NA
°F
°C
mA
Min DAT Ctrl= Yes Yes, No 6
Min DAT Limit= 55.0°F 0.0–70.0°F 4
Occ Heating= Yes Yes, No 6
Unocc Diff= 3°F 0–10°F 2
Htg Warmup Tm= 60s 0–999s 2
Htg Hld Period= 240s 0–999s 2
MWU Sensor= RAT
NonRAT
Space
4
coMMIssIon unIt
