D3 Set-Up Menu
The D3 Set-Up menu is provided for setting up an interface
with the unit via a D3 gateway. Refer to IM 1133 – DIII-Net
Communication Gateway for detailed information.
Table 35: D3 Setup Menu
Item Display
Name
Default
Setting
Range
Password
Level
Itouch Vers= — XXXXXXX 2
Unit D3 Addr=
1–100 1–00 to 8–15 2
Set D3 Addr= No No/Yes 2
OA Unit Num= 0 0–10 2
OA Unit Amps= 0 0–200 Amps 2
OA Unit Addr= 0 0–64 2
Set OA Unit=
No No/Yes 2
Rst All OA= No No/Yes 2
Min Load= 20% 0–100% 2
Max Load= 50% 0–100% 2
HiCapReset= No No/Yes 2
DATLoDiff= 10.0ºF 0–30ºF 2
Eco Method= None
None
2
Enth
OAT Hum
EnOAT Hum
DATHiDiff=
50ºF 0–20ºF 2
OA Enth Max= 25.5 BTU/lb 0–64.49 BTU/lb 2
OA Hum Max= 0.0107lb/lb 0–0.0300lb/lb 2
OAT Max= 84ºF 0–64.49ºF 2
Temp Display= DAT
None
2
DAT
Space
RAT
OAT
Low Speed= 33% 0–100% 2
Med Speed= 66% 0–100% 2
Hi Speed= 100% 0–100% 2
