Outdoor Air Fan Set-Up
Table 30: Outdoor Air Fan Set Up Menu
OA Fan1 Spd is a status only item that displays the current
speed of outdoor fan 1 in percent of maximum speed.
OA Fan1 Cmd= is is a status only item that indicates the
current command speed of outdoor fan 1.
OA Fan1 Amps is a status only item which displays the current
amperage being drawn by outdoor fan 1.
OA Fan2 Spd is a status only item that displays the current
speed of outdoor fan 2 in percent of maximum speed.
OA Fan2 Cmd= is is a status only item that indicates the
current command speed of outdoor fan 2.
OA Fan2 Amps is a status only item which displays the current
amperage being drawn by outdoor fan 2.
PTD is a status only item which displays the current discharge
refrigerant line pressure sensor reading.
PTS is a status only item which displays the current suction
refrigerant line pressure sensor reading.
Disch Sat Tmp is a status only item which displays the current
discharge pressure equivalent saturation temperature.
EffDshSatTSpt is a status only item which displays the
effective discharge saturation temperature set point used to
control the outdoor air fans in the cooling mode of operation.
OA Temp is a status only item which displays the current
temperature reading from the unit mounted outdoor air
temperature sensor.
INV Fin Temp is a status only item which displays the current
inverter compressor control board cooling n temperature.
This value is used in the inverter compressor n temperature
limiting protection function.
DischSatTDiff is an adjustable item which sets a differential
above the current outdoor air temperature reading which is
used to establish the EffDshSatTSpt.
DischSatTDB is an adjustable item which sets a control
deadband around the EffDshSatTSpt.
Item Display Name
Default
Setting
Range
Password
Level
OA Fan Status
OA Fan1 Spd= — 0–100% 4
OA Fan1 Cmd= — 0-100% 4
OAFan1 Amps= — 0–50A 4
OA Fan2 Spd= — 0–100% 4
OA Fan2 Cmd= — 0-100% 4
OAFan2 Amps= — 0–50A 4
Refrig Circuit Status
PTD= — 0–5000kPa 4
PTS= — 0–5000kPa 4
Disch Sat Tmp= — -50.0–212.0°F 4
EH DshSatTSpt= — -50.0–212.0°F 2
OA Temp= — -50.0–200.0°F 4
INV Fin Temp= — -50.0–200.0°F 2
OA Fan Set Up
DischSatTDiff= 15°F 10.0–50.0°F 2
DischSatTDB= 2.0°F 0–10.0°F 2
OA Fan Period= 10s 0–999s 2
OA Fan Gain= 2.0 0–100 2
OA Fan PAT= 20s 0–999s 2
IFB Comm Status
IFB SWVersion= — V0222013 2
IFBCommStatus= —
OK
2
OF2Err
OF1Err
OF12Err
INVErr
ACS3Err
ACS1Err
ACS13Err
Init3Err
Init1Err
Init13Err
IFBRst
MBErr
PrvCommStatus —
Same as IFB
CommStatus
2
MM/DD/YY HH:MM:SS — — 2
ACS1 DataRcvd= —
ErrAll
2
F1F2Err
INVF2Err
F2Err
INVF1Err
F1Err
INVErr
AllOK
ACS3 DataRcd= —
Error
2
OK
Fault Code Details (Active Fault Codes)
INVAlarmCode= — 2 digit alpha-numeric 2
Code Text — String 2
OF1AlarmCode= — 2 digit alpha-numeric 2
Code Text — String 2
OF2AlarmCode= — 2 digit alpha-numeric 2
Code Text — String 2
Fault Code Details (Previous Fault Codes)
PrvINVAlmCode= — 2 digit alpha-numeric 2
Code Text — String 2
MM/DD/YY HH:MM:SS — — 2
PrvOF1AlmCode= — 2 digit alpha-numeric 2
Code Text — String 2
MM/DD/YY HH:MM:SS — — 2
PrvOF2AlmCode= — 2 digit alpha-numeric 2
Code Text — String 2
MM/DD/YY HH:MM:SS — — 2
coMMIssIon unIt
