Daikin DPS - Alarm Menus; Alarm Configuration Menu

alarM Menus
Alarm Conguration Menu
Alarm Limits Menu
The Alarm Limits menu is used to set the limits of the discharge
air temperature sensor and the return air temperature sensor.
Table 36: Alarm Limits Setup Menu
Hi Disch Alm is an adjustable item that sets the high
temperature limit for the DAT sensor. When the discharge air
temperature sensor reaches this set point the unit will go into
the high discharge air alarm.
Lo Disch Alm is an adjustable item that sets the low
temperature limit for the DAT sensor. When the discharge air
temperature sensor reaches this set point the unit will go into
the low discharge air alarm.
Hi Return Alm is an adjustable item that sets the high
temperature limit for the return air temperature. When the RAT
sensor reaches this set point the unit will go into the high return
air temperature alarm.
Alarm Output Cong Menu
Table 37: Alarm Out Conguration Setup Menu
The digital alarm output indicates the alarm group that contains
the highest priority active alarm. This output is On when no
alarms are active. The options for the action of this output
when an alarm in a group occurs are On, Fast Blink, Slow
Blink, or Off. These can be edited via the keypad/display.
The default values for the three groups of alarms are:
• Warnings – Off
• Problems – Slow Blink
• Faults – Fast Blink
A user could eliminate any signal of a particular group of
alarms through this output by selecting On for that alarm group
in the keypad/display.
Alarm Delays Menu
The Alarm Delays Setup Menu can be accessed when a level 2
password has been entered. The default settings are the result
of many years of testing and should not be changed.
Table 38: Alarm Delays Setup Menu
Frz DelayTime is an adjustable item used to set the freeze
alarm delay time.
Aw Ignr Tm is an adjustable item that sets the amount of
time the air proving switch is ignored after the supply fan is
started.
Sens Alm Dly is an adjustable item used to set the sensor
alarm delay time.
Temp Alm Dly is an adjustable item used to set the
temperature alarm delay time
Emerg Stop is an adjustable item used to set the emergency
shutdown to either manual or automatic restart.
Item Display
Name
Default
Setting
Range
Password
Level
Hi Disch Temp= 170°F 90–250°F 4
Lo Disch Temp= 40°F -50–50°F 4
Hi Return Temp= 120°F 90–150°F 4
Item Display
Name
Default
Setting
Range
Password
Level
Faults= Fast
On
4
Off
Fast
Slow
Problems= Slow
On
4
Off
Fast
Slow
Warnings= Off
On
4
Off
Fast
Slow
Item Display
Name
Default Setting Range
Password
Level
Frz DelayTime= 30s 0–180s 2
Aw Ignr Tm= 120s 0–999s 2
Sens Alm Dly= 30s 0–300s 2
Temp Alm Dly= 30s 0–300s 2
Alarm Cong
Emerg Stop= Man Clr
Man Clr
Auto Clr
2
alarM Menus
www.DaikinApplied.com 59 OM 1141-3 • MICROTECH UNIT CONTROLLER
