Daikin DPS - Commission Unit; Unit Setup

coMMIssIon unIt
Unit Setup
Table 20: Unit Setup Menu
Space Sensor is an adjustable item to indicate if a space
sensor is connected to the unit controller or provided via a
network signal.
Eng Units is an adjustable item to indicate if the unit is to
display English or Metric units of measure.
Unit Name is an adjustable item that allows each controller
to be given a unique name. This may be useful when multiple
units are connected to a single remote HMI.
Rapid Start is an adjustable item that allows the user to select
to initiate a rapid startup sequence at unit power up.
Rapid Start Tm is an adjustable item that allows the user to
set the Rapid Start timing whenever the power is reset to the
controller and the controller nishes its startup sequence.
DO10 Cfg is an adjustable item that redenes the functionality
of digital output DO10 on the main control board. This output
is either a supply fan operation indication or a VAV box signal
depending on how this parameter is set.
Timer Settings Menu
Table 21: Timer Settings Menu
Service Time is an adjustable item that sets the amount of
time the internal control timers can be temporarily sped up.
Startup is an adjustable item that sets the time in seconds that
the unit will perform its startup operation.
Recirculate is an adjustable item that sets the time in seconds
that the unit operates with only the fan, recirculating the
building air upon unit start up.
Zero OA Time is an adjustable item that sets the time in
minutes that the outdoor air damper stays at a zero position
upon unit start up.
Tnt Override is an adjustable item that sets the amount of time
that the unit will go into operation when the tenant override
function is activated. Tenant override can be activated by the
space sensor button, the network occupancy mode parameter
or the keypad Occ Mode= parameter.
Post Heat is an adjustable item that sets the duration of the
post heat function available on VAV units.
Pwd Timeout is an adjustable item that sets the amount
of time in minutes that the controller will allow access to
applicable menus without re-entering the necessary password.
If the keypad display remains idle for this time period, the
display will revert to the “main menu” requiring a re-enter of the
password.
Item Display
Name
Default
Setting
Range
Password
Level
Space Sensor= Digtl/Net
None, Anlog/Net,
Digtl/Net
4
Eng Units= English English, SI 4
Unit Name= — — 4
Rapid Start= No No, Yes 2
Rapid Start Tm= 10 min 0–20 min 2
DO10 Cfg= FanOp
FanOp
VAVBox
2
Item Display
Name
Default
Setting
Range
Password
Level
Service Time 0 min 0–240min 4
Start Up 180s 1800s 4
Recirculate 180s 3600s 4
Zero OA Time 0 min 0–240min 4
Tnt Override 120 min 0–300min 4
Post Heat 0s 0–180s 4
Pwd Timeout 10 min 3–30min 4
Low DAT 6 min 0–60min 4
ClgStateDelay 300s 0–600s 4
Clg Stg Time 5 min 5–60min 4
Htg Stg Time 5 min 2–60min 4
Min Ex Strt Tm 120s 60–300s 4
Min Ex Stop Tm 120s 60–300s 4
ER Whl Stg Tm 5 min 1–100min 4
ER Whl Off Tm 5 min 1–100min 4
Air Flw Ign 120s 0–999S 2
Htg Wrmup Tm 240s 0–999s 2
Htg Hld Period 240s 0–999s 2
Srvc Time Inc 20s 0–300s 2
Off HtCl Delay 120s 0–999s 2
OM 1141-3 • MICROTECH UNIT CONTROLLER 34 www.DaikinApplied.com
coMMIssIon unIt
