Digital Output Status Menu
The Digital Output Status Menu provides diagnostic information to qualied service personnel. The items listed in this menu will
provide current status information of the controller’s digital outputs.
Table 47: Digital Output Status Menu
Network Input Status Menu
The Network Input Status Menu provides diagnostic information to qualied service personnel. The items listed in this menu will
provide current status information of the controller’s network inputs.
Table 48: Network Input Status Menu
Item Display
Name
Default
Setting
Range
Password
Level
Item Display
Name
Default
Setting
Range
Password
Level
MCB DO1= Off Off/On 2 EMB DO1= Off Off/On 2
MCB DO2= Off Off/On 2 EMB DO2= Off Off/On 2
MCB DO3= Off Off/On 2 EMB DO3= Off Off/On 2
MCB DO4= Off Off/On 2 EMB DO4= Off Off/On 2
MCB DO5= Off Off/On 2 EMB DO5= Off Off/On 2
MCB DO6= Off Off/On 2 EMB DO6= Off Off/On 2
MCB DO7= Off Off/On 2 EMD DO1= Off Off/On 2
MCB DO8= Off Off/On 2 EMD DO2= Off Off/On 2
MCB DO9= Off Off/On 2 EMD-DO3= Off Off/On 2
MCB DO10= Off Off/On 2 EMD-DO4= Off Off/On 2
EMD DO5= Off Off/On 2
EMD DO6= Off Off/On 2
Item Display Name
Default
Setting
Range
(No Network
value in Bold)
Password
Level
Item Display
Name
Default
Setting
Range
(No Network value
in Bold)
Password
Level
Net OAT In= —
-50.0–200.0°F
(621.8°F)
2 Net Cl Ena Vl= — 0–255% (255%) 2
Net SpaceT In= —
-0.0–150.0°F
(621.8°F)
2 Net Ht Ena Sw= — -1.0–1.0 (-1.0) 2
NetCurrState= —
Occ
2
Net Ht Ena Vl= — 0–255% (255%) 2
Unocc Net Ec Ena Sw= — -1.0–1.0 (-1.0) 2
TntOvrd Net Ec Ena Vl= — 0-255% (255%) 2
Standby Net SAF Cap= — 0–100% (164%) 2
Auto Net ExhF Cap= — 0–100% (164%) 2
(NULL) Net Space IAQ= —
0–5000ppm
(65535ppm)
2
NetNextState= —
Occ
2
Net Rel Humid= — 0-100% (164%) 2
Unocc Net DATClgSpt= — 40.0–100.0°F 2
TntOvrd Net DATHtgSpt= — 40.0–140.0°F 2
Standby nviSetpoint= —
0.0-100.0°F
(621.8°F)
2
Auto
OccManCmd= —
Occ
2
(NULL) Unocc
NetTmToNxtSt= —
0–65534min
(65535min)
2
TntOvrd
Standby
Net App Mode= —
Off
2
Auto
HeatOnly Net MinOA= — 0–100% 2
CoolOnly nvoEffSpt= — 0.0–100.0°F 2
FanOnly nciOccClgSpt= — 0.0–100.0°F 2
Auto nciOccHtgSpt= — 0.0–100.0°F 2
(Auto) nciHVACType= — HVT_GEN 2
Net Cl Ena Sw= — -1.0–1.0(-1.0) 2
serVIce Menus
