SiEBE18-526 Field Setting
Test Operation 117
Setting item 0 Display contents of “Various settings”
No. Setting item
LED display
Data display
H1P H2P H3P H4P H5P H6P H7P
0 Various settings
9777777
See below
5 Number of connected indoor units
9777878
Lower 6 digits
14
Contents of malfunction (the
latest)
9778887
Malfunction
code table
15
Contents of malfunction
(1 cycle before)
9778888
16
Contents of malfunction
(2 cycle before)
9787777
20 Contents of retry (the latest)
9787877
21 Contents of retry (1 cycle before)
9787878
22 Contents of retry (2 cycle before)
9787887
Setting item
H1P H2P H3P H4P H5P H6P H7P
Defrost select setting Short
9777877
Medium
9777977
Long
9777777
Te setting H
9777787
M
9777797
L
9777777
Tc setting H
9777778
M
9777779
L
9777777
c. Monitor mode
<Selection of setting item>
<Confirmation on setting contents>
To enter the monitor mode, push the
MODE button (BS1) when in “Setting
mode 1”.
Push the SET button (BS2) and set
the LED display to asetting item.
Push the RETURN button (BS3) to
display different data of set items.
Push the RETURN button (BS3) and
switches to the initial status of
“Monitor mode”.
∗ Push the MODE button (BS1) and
returns to “Setting mode 1”.
(V2765)
Push the SET button and match with the LEDs No. 1 - 15, push the RETURN button, and
enter the data for each setting.
H Data such as addresses and number of units is expressed as binary numbers; the two
ways of expressing are as follows:
The No. 5 cool/heat unified address is expressed as a binary
number consisting of the lower 6 digits. (0 - 63)
In c the address is 000110 (binary number), which translates to
4 + 2 = 6 (base 10 number). In other words, the address is 6.
9 797997
16 4 1
32 8 2
To Next Page
