Names of parts
Indoor Unit
Opening the front grille
How to open the grille
Air outlet selection switch
Thissetting blowsair from upper outlet only.
Thissetting automatically decidesablow
pattern depending on mode and conditions.
• Thissetting is
recommended.
• The unit isshipped from the
factory with thissetting.
Air outlet
selection
CAUTION
Before opening the front grille, be sure to stop the opera tion and turn the breaker OFF.
Do not touch the metal parts on the inside of the indoor unit, as it may result in injury.
