SiEBE18-526 Instruction
System Configuration 197
FTXS20/25/35C
.
Care and Cleaning
CAUTION
Before cleaning, be sure to stop the operation and
turn the breaker OFF.
Units
Indoor unit, Outdoor unit and Remote control
Front grille
1. Wipe them with dry soft cloth.
1. Open the front grille.
•
Hold the grille by the tabs on the two s idesand lift it
unitl it stops with a click.
2. Remove the front grille.
•
Supporting the front grille with one hand, release
the lock by sliding down the knob with the other
hand.
•
To remove the front grille, pull it toward yourself
with both hands.
3. Clean the front grille
•
Wipe it with asoft cloth soa ked in water.
•
Only neutral detergent may be used.
•
In case of washing the grille with water, dry it
withcloth, dry it up in the shade after washing.
4. Attach the front grille
•
Set the 3 keys of the front grille into the slots
and push them in all the way.
•
Close the front grille slowly and push the grille
at the 3 points.
(1 on each sidesand 1 in the middle.)
•
Check to see if the rotating axis in the upper
center section is moving.
Fit the key
into the slot.
CAUTION
•
Don’t touch the metal pa rts of the indoor unit. If you touch those parts, this may cause an injury.
•
When removing or attaching the front grille, use a robust and stable stool and watch your steps carefully.
•
When removing or attaching the front grille, support the grille securely with hand to prevent it from falling.
•
For cleaning, do not use hot water above 40
°
C, benzine, gasoline, thinner, nor other volatile oils,
polishing compound, scrubbing brushes, nor other hand stuff.
•
After cleaning, make sure that the front grille issecurely fixed.
To Next Page
