6. Installthetopcovers.RefertoSection4.1CompressorCoversonpage52.
7. Returnthecompressortonormaloperation.

4.17.2.5 Soft Start AC/DC Harness Torque Specifications

Table 4-27 Soft Start AC/DC Harness Torque Specifications
Description Nm Ft.Lb. In.Lb.
ACBusBartoSCRfastener,M5x16 5 - 44
SoftStartDC+&DC-toDCBusBolt/nut(TTS300/TGS230only) 10 7 89
CoverFastener,M5x15 1.5 - 13

