Figure 6-1 Module Removal
5. RemovetheMotor-CoolingValveSolenoidCoilsbyremovingtheretainingnutoneachsolenoid.
• • • CAUTION • • •
ThesolenoidactuatorsarededicatedonallmodelsexceptTT300/TG230.Noteactuatorpositionbeforeremoval.

6. Dryoffanycondensatearoundthesolenoids.
Figure 6-2 Motor Cooling Valve Solenoids
7. RemoveanydebrisordustfromBackplaneBoardandsolenoidsusingasoft-bristlebrush.
6.2.1.2 Service Side Assembly
1. Applyathincoatingofdielectricgreasetotheexteriorofthebearingsensorfeedthroughconnectors.

