4.9.4 IGV Torque Specifications
Table 4-16 IGV Torque Specifications
Description Nm Ft.Lb. In.Lb.
IGVHousingFastener,M10x40 22 16 195
IGVFeedthroughFastener,M5x16 5 - 44
IGVMotorSetscrew,M5x8 5 - 44
IGVThroatFastener,M6x55 5 - 44
LockingCollar 5 - 44

