the๎following๎three๎(3)๎steps.
๎7.๎ Keeping๎the๎red๎(+)๎multimeter๎lead๎on๎the๎phase๎1๎AC๎terminal,๎place๎the๎black๎(-)๎multimeter๎lead๎on๎
the๎DC-๎terminal.๎The๎measured๎value๎should๎be๎open.
๎8.๎ Place๎the๎black๎(-)๎multimeter๎lead๎on๎the๎phase๎1๎AC๎terminal๎and๎the๎red๎(+)๎multimeter๎lead๎on๎the๎
DC+๎terminal๎and๎record๎the๎results.๎The๎measured๎value๎should๎be๎open.
๎9.๎ Keeping๎the๎black๎(-)๎multimeter๎lead๎on๎the๎phase๎1๎AC๎terminal,๎place๎the๎red๎(+)๎multimeter๎lead๎on๎
the๎DC-๎terminal.๎The๎measured๎value๎should๎be๎0.275V๎โ๎0.4V.
๎10.๎ Repeat๎Steps๎6๎through๎9๎for๎the๎remaining๎Inverter๎phases.
NOTE
These๎values๎can๎vary๎depending๎on๎the๎meter๎being๎used.๎The๎main๎idea๎is๎that๎the๎values๎be๎consistent๎between๎phases.
๎
Figure 4-190 Inverter Diode Measurements (Skiip 613 Shown)
4.22.3 Inverter Cable Harness
๎
Figure 4-191 Inverter Cable Harness
4.22.4 Inverter Cable Harness Removal and Installation
๎
4.22.4.1 Inverter Cable Harness Removal
๎1.๎ Isolate๎the๎compressor๎power๎as๎described๎in๎Section๎1.8๎๎Electrical๎Isolation๎on๎page๎22.
๎2.๎ Remove๎the๎Service๎Side๎Cover.๎Refer๎to๎Section๎4.1.3.1๎๎Service๎Side๎Cover๎Removal๎and๎Installation๎on๎
page๎54.
๎3.๎ Remove๎the๎Soft๎Start.๎Refer๎to๎Section๎4.14.3๎๎Soft๎Start๎Removal๎and๎Installation๎on๎page๎117.
๎4.๎ Use๎two๎(2)๎fingers๎to๎simultaneously๎push๎outward๎on๎the๎Inverter๎Cable๎Harness๎latches.๎Refer๎to๎
Figure๎4-192๎๎Harness๎Removal๎from๎Inverter๎on๎page๎178.
๎
M-SV-001-EN Rev. H-1/23/2023 Page 177 of 294
