Figure 4-210 Driver Board Fasteners

6. CarefullylifttheDriverBoardvertically.
Figure 4-211 Carefully lift the Driver Board vertically.
7. SetasidetheDriverBoardfastenersforre-use.
8. DiscardtheoldDriverBoardinaccordancewithlocalregulations.

• • • CAUTION • • •
Donotmoveortouchanyspringpinsunlesstheyarenotinproperalignment.Damageormisalignmentofspringpinscancausefailureof
theentireInvertermodule.

4.22.7.2 Inverter Control Card Installation
ESDprotectionmustbewornwhenhandlingthedriverboard.
1. Verifythatallspringpinsarepresent(totalof13pins)andthattheyareinproperalignment.Referto
Figure4-212SeatedSpringPinsonpage190.

M-SV-001-EN Rev. H-1/23/2023 Page 189 of 294
