Danfoss Turbocor TT300 User Manual

129 of 132
M-SV-001-EN Rev.E
Component Test Point Expected Value
Verification
Section
Measured Value
F4 & F5 30-38Ω 3.4.3.2
Solenoid Actuators 4.8 W 108Ω – 132Ω 3.12.3
9.3 W 56.25Ω – 68.75Ω 3.12.3
Stator Resistance Phase 1:2 > 0.0Ω and < 1Ω 3.8.4.2
Phase 1:3 > 0.0Ω and < 1Ω 3.8.4.2
Phase 2:3 > 0.0Ω and < 1Ω 3.8.4.2
Stator Thermistor Resistance + to -
150-300 Ω at 70°F
(21°C)
3.8.4.3
Appendix C Compressor Test Sheet
