Danfoss VLT AHF 005 User Manual

Table 114: Mains Contactor Switches for N710–N800 Models, 525–690 V
N710
N800
IEC
580 A/1000 V
820 A/1000 V
Eaton P/N
XTCE580N22A
XTCE820N22A
UL
820 A/1000 V
1000 A/1000 V
Eaton P/N
XTCE820N22A
XTCEC10N22A
10.8.3 Fusible Disconnect Switches
The fusible disconnector switch is an option that safely isolates the drive from the mains with a fuse switch mounted below the
drive module. All units ordered and supplied with a factory-installed fusible disconnect switch have a fuse built in to the switch. The
fuse has been sized to meet 65kA SCCR for the system. The input voltage and power rating of the drive determines the specific class
or gG fuse. The input voltage and power rating are found on the product nameplate.
Table 115: Fusible Disconnect Switches for N110–N315 Models, 380–480 V
N110
N132
N160
N200
N250
N315
IEC
400 A/690 V
400 A/690 V
400 A/690 V
630 A/690 V
630 A/690 V
630 A/690 V
ABB P/N
OS400D30P
OS400D30P
OS400D30P
OS630D30P
OS630D30P
OS630D30P
UL
400 A/600 V
400 A/600 V
400 A/600 V
600 A/600 V
600 A/600 V
800 A/600 V
ABB P/N
OS400J30
OS400J30
OS400J30
OS600J30
OS600J30
OS800L30
Table 116: Fusible Disconnect Switches for N355–N560 Models, 380–480 V
N355
N400
N450
N500
N560
IEC
1250 A/690 V
1250 A/690 V
1250 A/690 V
1250 A/690 V
1250 A/690 V
ABB P/N
OS1250D30P
OS1250D30P
OS1250D30P
OS1250D30P
OS1250D30P
UL
800 A/600 V
1200 A/600 V
1200 A/600 V
1200 A/600 V
1200 A/600 V
ABB P/N
OS800L30
OS1200L30
OS1200L30
OS1200L30
OS1200L30
Table 117: Fusible Disconnect Switches for N110–N315 Models, 525–690 V
N110
N132
N160
N200
N250
N315
IEC
400 A/690 V
400 A/690 V
400 A/690 V
630 A/690 V
630 A/690 V
630 A/690 V
ABB P/N
OS400D30P
OS400D30P
OS400D30P
OS630D30P
OS630D30P
OS630D30P
UL
400 A/600 V
400 A/600 V
400 A/600 V
400 A/600 V
400 A/600 V
600 A/600 V
ABB P/N
OS400J30
OS400J30
OS400J30
OS400J30
OS400J30
OS600J30
Table 118: Fusible Disconnect Switches for N400–N630 Models, 525–690 V
N400
N450
N500
N560
N630
IEC
630 A/690 V
630 A/690 V
1250 A/690 V
1250 A/690 V
1250 A/690 V
ABB P/N
OS630D30P
OS630D30P
OS1250D30P
OS1250D30P
OS1250D30P
UL
600 A/600 V
600 A/600 V
800 A/600 V
800 A/600 V
800 A/600 V
ABB P/N
OS600J30
OS600J30
OS800L30
OS800L30
OS800L30
AQ262141314214en-000301 / 130R0880 | 171Danfoss A/S © 2021.11
Specifications
VLT® HVAC Drive FC 102
Operating Guide
