13-42 Logic Rule Boolean 2
Array [6]
Option: Function:
[38] Digital input DI33
[39] Start command
[40] Drive stopped
[41] Reset Trip
[42] Auto Reset Trip
[43] OK Key
[44] Reset Key
[45] Left Key
[46] Right Key
[47] Up Key
[48] Down Key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[75] Start command given
[76] Digital input x30/2
[77] Digital input x30/3
[78] Digital input x30/4
[80] No Flow
[81] Dry Pump
[82] End of Curve
[83] Broken Belt
[90] ECB Drive Mode
[91] ECB Bypass Mode
[92] ECB Test Mode
[93] Emergency Mode
[94] RS Flipop 0 See parameter 13-15 RS-FF Operand
S, parameter 13-16 RS-FF Operand R.
[95] RS Flipop 1 See parameter 13-15 RS-FF Operand
S, parameter 13-16 RS-FF Operand R.
[96] RS Flipop 2 See parameter 13-15 RS-FF Operand
S, parameter 13-16 RS-FF Operand R.
[97] RS Flipop 3 See parameter 13-15 RS-FF Operand
S, parameter 13-16 RS-FF Operand R.
[98] RS Flipop 4 See parameter 13-15 RS-FF Operand
S, parameter 13-16 RS-FF Operand R.
[99] RS Flipop 5 See parameter 13-15 RS-FF Operand
S, parameter 13-16 RS-FF Operand R.
[100] RS Flipop 6 See parameter 13-15 RS-FF Operand
S, parameter 13-16 RS-FF Operand R.
[101] RS Flipop 7 See parameter 13-15 RS-FF Operand
S, parameter 13-16 RS-FF Operand R.
[102] Verifying Flow
13-42 Logic Rule Boolean 2
Array [6]
Option: Function:
[103] Relay 1
[104] Relay 2
[105] Relay 3
[106] Relay 4
[107] Relay 5
[108] Relay 6
[109] Relay 7
[110] Relay 8
[111] Relay 9
[112] System On Ref
[125] Digital input x46/1
[126] Digital input x46/3
[127] Digital input x46/5
[128] Digital input x46/7
[129] Digital input x46/9
[130] Digital input x46/11
[131] Digital input x46/13
[140] ATEX ETR cur.
warning
[141] ATEX ETR cur. alarm
[142] ATEX ETR freq.
warning
[143] ATEX ETR freq. alarm
Parameter Description Programming Guide
MG20OB02 Danfoss A/S © 05/2018 All rights reserved. 125
