Page #142 background imageLoading...
Page #142 background image
14-62 Inv. Overload Derate Current
Range: Function:
95 %* [50 -
100 %]
Enter the current level (in % of rated output
current for the frequency converter) when
running with reduced pump speed after load
on the frequency converter has exceeded
the allowable limit (110% for 60 s).
3.13.9 14-8* Options
14-80 Option Supplied by External 24VDC
Option: Function:
NOTICE
This parameter is only changing function by
performing a power cycle.
[0] No Select [0] No to use the frequency converter's 24 V DC
supply.
[1] * Yes Select [1] Yes if a 24 V DC external supply is used to
power the option. Inputs/outputs are galvanically
14-80 Option Supplied by External 24VDC
Option: Function:
isolated from the frequency converter when operated
from an external supply.
3.13.10 14-9* Fault Settings
14-90 Fault Level
Array [21]
Option: Function:
[0] O Use this parameter to customize fault
levels. Use [0] O with caution as it
ignores all warnings and alarms for the
selected source.
[1] Warning
[2] Trip
[3] Trip Lock
[4] Trip w. delayed
reset
Failure Parameter Alarm O Warning Trip Trip lock Trip with delayed reset
10 V low 1490.0 1 X D
24 V low 1490.1 47 X D
1.8 V supply low 1490.2 48 X D
Voltage limit 1490.3 64 X D
Ground fault
1490.4
1)
14 D X
Ground fault 2
1490.5
1)
45 D X
Torque limit 1490.6 12 X D
Overcurrent 1490.7 13 D X
Short circuit 1490.8 16 X D
Heat sink temp. 1490.9 29 X D
Heat sink sensor 1490.10 39 X D
Control card temp. 1490.11 65 X D
Power card temp. 1490.12 69 X D
Heat sink temp.
1490.13
3)
244 X D
Heat sink sensor
1490.14
3)
245 X D
Power card temp.
1490.15
3)
247 X D
Derag limit fault
1490.16
1), 2)
100 D X
Table 3.22 Possible Actions when Selected Alarm Appears
D = Default setting. X = Possible selection.
1) Only these faults are congurable on the FC 202. Due to a software limitation with array parameters, all others are shown in the MCT 10 Set-
up Software. For the other parameter indices, writing any other value than its current value (that is, the default value) returns a value-out-of-
range error. Thus, it is not allowed to change the fault level for the non-congurable ones.
2) This parameter has been 1490.6 in all rmware versions up to 1.86.
3) Alarm 244, Heat sink temp., alarm 245, Heat sink sensor, and alarm 247, Power card temp. are used for multiple power cards.
Parameter Description
VLT
®
AQUA Drive FC 202
140 Danfoss A/S © 05/2018 All rights reserved. MG20OB02
