3.24.11 27-7* Connections

Parameters for conguring relay connections.

27-70 Relay

This parameter is only relevant for a relay wiring conguration.

Use this parameter to set up the function of the option relays.

This parameter is an array. The visibility of options depends on

the MCO option installed in the frequency converter:

•

VLT

Extended Cascade Controller MCO 101: Relays 10–

12 are available.

•

VLT

Advanced Cascade Controller MCO 102: Relays

13-20 are available.

In any case, the standard relays (Relay 1 and Relay 2), and the

relays in the VLT

Relay Option MCB 105 are available.

To set the function of a specic relay, select the relay and then

select the function. If the option [0] Standard Relay is selected,

the relay can be used as a general-purpose relay and the

function can be set in parameter group 5-4* Relays.

Option: Function:

[0] * Standard Relay Enable slave

frequency

converter X.

[1] Drive 2 Enable

[2] Drive 3 Enable

[3] Drive 4 Enable

[4] Drive 5 Enable

[5] Drive 6 Enable

[6] Drive 7 Enable

[7] Drive 8 Enable

[8] Pump 1 to Drive 1

[9] Pump 1 to Drive 2

[10] Pump 1 to Drive 3

[11] Pump 1 to Drive 4

[12] Pump 1 to Drive 5

[13] Pump 1 to Drive 6

[14] Pump 1 to Drive 7

[15] Pump 1 to Drive 8

[16] Pump 2 to Drive 1

[17] Pump 2 to Drive 2

[18] Pump 2 to Drive 3

[19] Pump 2 to Drive 4

[20] Pump 2 to Drive 5

[21] Pump 2 to Drive 6

[22] Pump 2 to Drive 7

[23] Pump 2 to Drive 8

[24] Pump 3 to Drive 1

[25] Pump 3 to Drive 2

[26] Pump 3 to Drive 3

[27] Pump 3 to Drive 4

[28] Pump 3 to Drive 5

[29] Pump 3 to Drive 6

[30] Pump 3 to Drive 7

[31] Pump 3 to Drive 8

27-70 Relay

This parameter is only relevant for a relay wiring conguration.

Use this parameter to set up the function of the option relays.

This parameter is an array. The visibility of options depends on

the MCO option installed in the frequency converter:

•

VLT

Extended Cascade Controller MCO 101: Relays 10–

12 are available.

•

VLT

Advanced Cascade Controller MCO 102: Relays

13-20 are available.

In any case, the standard relays (Relay 1 and Relay 2), and the

relays in the VLT

Relay Option MCB 105 are available.

To set the function of a specic relay, select the relay and then

select the function. If the option [0] Standard Relay is selected,

the relay can be used as a general-purpose relay and the

function can be set in parameter group 5-4* Relays.

Option: Function:

[32] Pump 4 to Drive 1

[33] Pump 4 to Drive 2

[34] Pump 4 to Drive 3

[35] Pump 4 to Drive 4

[36] Pump 4 to Drive 5

[37] Pump 4 to Drive 6

[38] Pump 4 to Drive 7

[39] Pump 4 to Drive 8

[40] Pump 5 to Drive 1

[41] Pump 5 to Drive 2

[42] Pump 5 to Drive 3

[43] Pump 5 to Drive 4

[44] Pump 5 to Drive 5

[45] Pump 5 to Drive 6

[46] Pump 5 to Drive 7

[47] Pump 5 to Drive 8

[48] Pump 6 to Drive 1

[49] Pump 6 to Drive 2

[50] Pump 6 to Drive 3

[51] Pump 6 to Drive 4

[52] Pump 6 to Drive 5

[53] Pump 6 to Drive 6

[54] Pump 6 to Drive 7

[55] Pump 6 to Drive 8

[56] Pump 7 to Drive 1

[57] Pump 7 to Drive 2

[58] Pump 7 to Drive 3

[59] Pump 7 to Drive 4

[60] Pump 7 to Drive 5

[61] Pump 7 to Drive 6

[62] Pump 7 to Drive 7

[63] Pump 7 to Drive 8

[64] Pump 8 to Drive 1

[65] Pump 8 to Drive 2

[66] Pump 8 to Drive 3

[67] Pump 8 to Drive 4

[68] Pump 8 to Drive 5

[69] Pump 8 to Drive 6
